Project Description

AVAILABLE COLOURS

FRAME & FORKS

yellow/blue/white/black

CASE OF TFWS

black

FRONT HUBS

silver

CRANCKSET

silver

MOTOR

white/polished

GRIP

black and grey

FRAME & FORKS

Unisex, chromoly steel, fits all driver heights from 1,5 m to 1,95 m

MOTOR

ZEHUS ALL IN ONE, rear hub, 250 W, with KERS (self charging whilst braking)

MAX ASSISTED SPEED

25 km/h

RANGE

30+ km with full electric assistance

BATTERY

Integrated in the rear hub, 30V Li-ion 160 Wh, life > 1.000 cycles

CHARGING TIME

100% in only 3 hours with a charger

CRANKSET

STURMEY-ARCHER FCT 64AA, 44 Teeth, Al 7075

REAR SPROCKET

POINT, 15 Teeth

CHAIN

KMC, anti rust

PEDALS

ERGOTEC 191, aluminium alloy with rubber surface, industrial ball bearing

RIMS

Aluminium alloy, double wall, 36 holes, 20” rear and 16” front

TIRES

SCHWALBE BIG APPLE, 20” 50-406 rear and 16” 50-305 front

FRONT HUBS

STURMEY-ARCHER HBT30, Al 7075

SPOKES

SAPIM, silver, stainless steel

BRAKE SYSTEM

SACCON, front and rear mechanical V-brakes

GRIPS

ERGOTEC Frisko 2

STEM RISER

ERGOTEC Octopus 50 XL/31.8, Al 6061 T6, adjustable 0°- 60°

HEADSETS

ERGOTEC A118AC-ES, 1 1/8″ Aluminium headset threadless with sealed cartridge bearings

SADDLE

SELLE ROYAL Freeway City, unisex, with royal gel

FRONT LIGHT

SPANNINGA Trigon 25, removable & USB-rechargeable

REAR LIGHT

SPANNINGA Solo XBA, with light-motion sensor

MUDGUARDS

SKS, rear and front

LOAD CAPACITY

FRONT: 7 kg    MIDDLE: 20 kg     REAR: 25 kg

FRONT CARRIER

RIXEN & KAUL KLICK FIX , Vario Rack or Lamello basket (18 l) included

MIDDLE CARRIER

TRIS Bike design, with elastic string, max width of luggage: 12 cm

REAR CARRIER

ATRAN VELO Active, aluminium alloy

WEIGHT

26 kg

DIMENSIONS

L:150 x W:60 x H:113 cm

MAX RIDER WEIGTH

110 kg
